SiBE12-314 Outdoor Unit
Removal Procedure 137
Make sure that the seven
claws are fit securely when
reassembling.
2. Remove the top panel.
1
Loosen the four screws
and lift the top panel.
2
Loosen the seven
screws of the front
panel.
Step
Procedure Points
