Heat Pump SiBE12-314
16 Specifications
Heating [230V]
50Hz
Notes:
1. Cooling capacity is based on 27°CDB/19°CWB (Indoor temperature), 35°CDB (Outdoor temperature).
Heating capacity is based on 20°CDB (Indoor temperature), 7°CDB/6°CWB (Outdoor temperature).
2. It is impossible to connect the indoor unit for one room only.
3D040483#1
Combination of
indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A)
Power factor
(%)
A room B room — — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2.5 3.40 — — — 3.40 1.20~4.10 1135 380~1600 5.2 2.1~7.5 95
3.5 3.80 — — — 3.80 1.20~4.40 1350 380~1850 6.2 2.1~8.6 95
2.5+2.5 2.20 2.20 — — 4.40 1.50~4.70 1190 340~1420 5.4 1.8~6.6 96
2.5+3.5 2.05 2.35 — — 4.40 1.50~4.70 1190 340~1420 5.4 1.8~6.6 96
