SiBE12-314 Heat Pump
Specifications 15
2.2 Outdoor Units
Notes:
1.
★
See “Combination Capacity”.
2. The data are based on the conditions shows in the table below.
Combination Capacity
Cooling [230V]
50Hz
230V, 50Hz
Model
2MXS40BVMB 2AMXS40BVMB
Cooling Heating Cooling Heating
Cooling Capacity
★
kW — —
Power Consumption
★
W— —
Running Current
★
A— —
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23GXD 1YC23GXD
Motor Output W 600 600
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.40 0.40
Refrigerant
Type R410A R410A
Charge kg 1.20 1.20
Air Flow Rate
m³/min
HH 39 35 39 35
H35323532
L30273027
cfm
HH 1126 1010 1126 1010
H 1010 924 1010 924
L 866 779 866 779
Fan
Type Propeller Propeller
Motor Output W 50 50
Starting Current A 6.2 6.2
Dimension (H
×
W
×
D) mm 640
×
685
×
285 640
×
685
×
285
Packaged Dimension (W
×
D
×
H) mm 800
×
366
×
676 800
×
366
×
676
Weight kg 39 39
Gross Weight kg 42 42
Operation
Sound
Sound Pressure
dBA47484748
Silent Mode
dBA43444344
Sound Power dBA 62 — 62 —
Piping
Connection
Liquid mm
φ
6.4
×
2
φ
6.4
×
2
Gas mm
φ
9.5
×
2
φ
9.5
×
2
Drain mm
φ
18
φ
18
Heat Insulation Both Liquid & Gas Pipes Both Liquid & Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Piping Length m
30 (for Total of Each Room) 30 (for Total of Each Room)
20 (for One Room) 20 (for One Room)
Min. Piping Length m 1.5 (for One Room) 1.5 (for One Room)
Amount of Additional Charge g/m 20 (20m or more) 20 (20m or more)
Max. Installation Height Difference m
15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D040482 3D040483
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
Combination of
indoor unit
Each capacity (kW) Total capacity (kW) Total input (W) Total current (A)
Power factor
(%)
A room B room — — Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating
2.5 2.50 — — — 2.50 1.20~3.00 755 340~1020 3.5 1.9~4.7 94
3.5 3.15 — — — 3.15 1.20~3.60 1120 340~1440 5.1 1.9~6.5 95
2.5+2.5 1.95 1.95 — — 3.90 1.50~4.20 1215 400~1490 5.6 2.2~6.8 94
2.5+3.5 1.75 2.15 — — 3.90 1.50~4.20 1215 400~1490 5.6 2.2~6.8 94
