SiBE12-314 Outdoor Unit
Removal Procedure 149
1.4 Removal of the Sound Blanket
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1
Loosen the five screws
of the right side panel.
2
Release the clamp of
the compressor lead
wire from the partition
plate.
