Instruction manual
Very important: Read this manual carefully before using your refrigerator.
This manual is designed with texts corresponding to drawings.
Installation
Identify the model of your refrigerator (“a”
or “b”) by comparing the control panel with the
illustrations.
1.1 Unpacking. Remove all protective materials.
1.2 Placement. Place the refrigerator away
from heat sources and protect it from direct
sunlight in order to conserve energy.
Do not install the refrigerator in the open air
or where it is exposed to rain.
Air should be able to circulate behind the
refrigerator. Leave 25 mm between the
rear of the refrigerator and the wall. Do not
enclose the space between the refrigerator
and the fl oor or ceiling with any object.
Level the refrigerator to prevent vibration and
noise. Remember that if the refrigerator is
situated next to a wall or cupboard, it could
make some noise.
In addition, make sure that the trays are
correctly placed and position the containers
with a space between them to prevent
vibration.
1.3 Connecting to power. Let the refrigerator
sit in an upright position for at least 2 hours
before connecting it. Check the information
on the specifi cation plate (220-240V with
ground wire) (1.3.1, 1.3.2).
Do not use adapters or extension leads.
Prevent the cord from coming in contact with
the motor or getting trapped beneath it.
1.4 Changing the side that the door opens
from. Disconnect the refrigerator from the
power outlet and empty the inside of the
door.
Remove the upper hinge cover with a fl at
blade screwdriver (1.4.1). Loosen the screws
and remove the hinge mechanism with help
of a screwdriver (1.4.2).
Loosen the connector pressing the tab.
(1.4.3). Remove the refrigerator door (1.4.4).
Remove the controls with a screwdriver,
prying it away using the grooves placed for
that purpose (1.4.5).
0
Identifi cation
english
Make a notch for the cable on the opposite
side, as marked on the casing (1.4.6).
Remount the control panel passing the cable
through the notch you made (1.4.7)
Remove the screw cover from the central
hinge, loosen the screws and remove the
hinge (1.4.8). In the models with three
compartments, swap the top and bottom
hinges. Remove the freezer door (1.4.9).
Loosen the screws of the lower hinge and
remove it. Change the position of the hinge axis
and place it on the opposite side (1.4.10).
Place the lower freezer handle on the
refrigerator door and the lower refrigerator
handle on the freezer door, rotated 180º.
Place the vertical handles on the opposite
side rotating them 180º (1.4.11). If you have a
centre compartment, place the upper handle
below, and the lower handle above, rotated
180º.
Rotate the self-closures and place the one
from the refrigerator on the freezer and vice
versa (1.4.12).
Position the freezer door (1.4.13) and attach
the central hinge (1.4.14). Position the
refrigerator door (1.4.15).
Place the closure mechanism in the upper
hinge space on the opposite side (1.4.16).
Put the cable through the upper hinge and
rotation mechanism and plug it into the door
connector (1.4.17).
Screw in the upper hinge (1.4.18) and put the
cover in place (1.4.19).
2.1 Switching on the refrigerator. Press
until
a temperature can be seen on the screen.
After installation, the refrigerator will stay
switched on once it is plugged in.
2.2 Confi guration. Press
for 5 seconds
and you will see the different confi guration
options (language, date, time, warnings…)
(2.2.1). Select the option that you would like
to confi gure by pressing
(2.2.2). Change
the option by pressing the
or
key
(2.2.3). Verify by pressing
(2.2.4). To exit
the menu press
for 5 seconds (2.2.5).
2.3 Selecting the compartment. In combination
refrigerators, the refrigerator
freezer
and third compartment operate
independently. Press
until it blinks to
2
Operation
