![Daikin EHSH08P30A [37/68] Final shutdown](/views2/1786267/page37/bg25.png)
5 x Decommissioning
Daikin Altherma EHS(X/H)
Daikin Solar tank with integrated interior heat pump unit
008.1420744 – 06/2015
Installation and maintenance manual
37
5.2 Final shutdown
WARNING!
Cooling systems (heating pumps), climate control
systems and heating devices that are incorrectly dis-
mantled can both endanger the life and health of
people and exhibit impaired function during start-up.
● Work on the Daikin Altherma EHS(X/H) (such as
dismantling components, temporary or final
shutdown of system) is only to be carried out by
persons who are authorised and who have
successfully completed qualifying technical or
vocational training for the specific activity and
who have taken part in advanced training sessions
recognised by the relevant responsible authorities.
These include, in particular, certified heating
engineers, qualified electricians and HVAC
specialists, who on account of their professional
training and expert knowledge, have experience
in the professional installation and maintenance of
heating, cooling and air conditioning systems and
heat pumps.
● You m
ust observe the warning and safety
instructions in the installation manual on working
in the coolant system.
A final shutdown may be necessary if
– the system is defective and is bein
g dismantled and disposed
of.
– components of the system are defective, are bei
ng disman-
tled and replaced.
– the system or parts of the
system are being dismantled and
reassembled in another location.
The Daikin Altherma EHS(X/H) is designed to be environmentally
frie
ndly and easy to install: the jobs described above can
therefore be carried out in an efficient and environmentally-
friendly manner.
When changing location or replacing parts on the coolant system
in the pipe network:
● Pump th
e coolant back into the external heat pump unit
(see installation and operating guid
e for the particular
external heat pump unit).
When disposing of the machine or repl
acing parts in the coolant
system:
● Suction the coolant
from the machine and recycle
(see installation and operating guide for the particular
external heat pump unit).
CAUTION!
Coolant escaping from the system causes long-term
damage to the environment.
Mixing different kinds of coolant can result in hazard-
ous toxic gases being released. Mixing with oils when
coolant escapes can lead to the soil being contami-
nated.
● Neve
r allow coolant to be released into the atmos-
phere - always suction it off and recycle using a
suitable recycling device.
● Alway
s recycle coolant, in so doing keeping it
separated from oils and other additives.
● Only store different types of coolant separately, in
suitable pressure vessels.
● Disp
ose of coolants, oils and additives properly
and in accordance with the applicable national
regulations of the country it is being used in.
● Deco
mmissioning a Daikin Altherma EHS(X/H)
(see section 5.1).
● Disconnect the Daikin Altherma EHS(X/H) from all electrical
connections, coolant and water connections.
● Disman
tle the Daikin Altherma EHS(X/H) or components in
accordance with the installation guide in reverse order.
● Dai
kin Altherma EHS(X/H) disposed off in a professional
manner.
Recommendations for disposal
The Daikin Altherma EHS(X/H) has an environmentally-friendly
design. During the disposal process, the only waste created is
that which can be used for material or thermal recycling. The ma-
terials used that are suitable for recycling can be sorted into indi-
vidual types.
Daikin has complied with the standards for environmen-
tally-friendly disposal as a result of the environmentally-
friendly design of the Daikin Altherma EHS(X/H).
Proper disposal in compliance with the respective
national regulations of the country of use is the respon-
sibility of the user/owner.
The designation of the product means that electrical
and electronic products may not be disposed of
together with unsorted domestic waste.
Proper disposal in compliance with the respective
n
ational regulations of the country of use is the respon-
sibility of the user/owner.
– Disassembly of the system,
handling of coolant,
oil and other parts may only be carried out by a
qualified fitter.
– Disposal may only be carried out by an organi-
zation that specialises in reuse, recycling and
recovery.
Further information is available from the installation
co
mpany or the responsible local authorities.
