Binatone JE-800 [6/30] Assembling

BEFORE FIRST USE

 Read the instruction manual below.

 Remove all of the packing materials from the

juicer.

 Wash thoroughly all of the juicer parts that may

contact the food.

 Check if the appliance is assembled properly

(see section “Assembling”).

INSTRUCTION MANUAL

Assembling

1. Place the juicer upon a dry clean horizontal sur-

face.

2. Place the separator (6) upon the juicer case

(10) at approx. 30–40° angle and fix it by turn-

ing counter-clockwise until a click is heard (see

Picture B).

3. Put the grater-filter (9) over separator (6) so that the former locks

on its fixing piece (11); check if it rotates freely.

Note: when disassembling the appliance remove the grater-

filter (9) together with the separator (6); to do that

turn the separator clockwise at 30–40°, pull it

upwards, and then remove the grater-filter (9).

4. Close the juicer with the lid (3). To do that, press the latches (4)

upper parts, carefully put the lid on the separator (6) and release

the latches to firmly fix the lid on the juicer case. Check if the lid is

fixed properly.

Note: Your juicer is equipped with an automatic protection

system. The appliance will not work if the latches (4)

or the lid (3) are not closed and it will automatically

turn itself off if they are accidentally opened during

the process.

5. Place the pulp collector (14) under the pulp outlet (8), then put the

measuring glass for juice (13) under the separator nozzle (6).

The foam separator is intended to separate the foam from the juice.

Collect the juice in the main compartment of the measuring glass

(13), and whilst serving it through the spout - the foam will remain

at the bottom of the measuring glass (13). You may use any other

jug of appropriate size instead of the measuring glass (13).

6. Your juicer is has as anti-drip system. When the appliance is not in

use, snap up the nozzle (7), which will prevent the juice dripping

onto your table. Before using the juicer always open the nozzle

(7) to prevent juice from lingering in the separator. Never load

products into the juicer with the nozzle shut.

7. Install the hopper (2) on the product inlet (5) so that you may place

the fruit and vegetables there while making juice. Because the hop-

per (2) profile is exactly the same as the lid (3) one, when putting

the juicer away for storage just turn the hopper over to save space.
