TR
Püskürtme borusunu hızlı kaplin üzerinden cihaza bağlayın.
Bunun için fişli bağlantıyı tutun. Hafifçe bastırarak, fişli bağlantının
yerine oturduğu duyulana kadar vakum bağlantı ağzının önündeki hızlı
kapline yerleştirin.
Teleskopik boruyu uygun tarafından vakum hortumunun tutamağı-
na ve yıkama başlığını da teleskopik boruya bağlayın.
Püskürtme borusunun iki tutma klipsini teleskopik boruya tespit
edin. Püskürtme borusunu tutma klipsine takın.
Püskürtme kolunu tutamağa oturtun.
Bunun için püskürtme kolunun plastik kanatçığını tutamakta bulunan
girintiye sürün. Püskürtme kolunun doğru olarak kilitlenmesine dikkat
edin (işaretine bakın).
Yıkama başlığının püskürtme borusunu hızlı kaplin üzerinden
tutamağa bağlayın.
Bunun için yıkama vakum başlığının serbest ucunu tutun. Bunu püs-
kürtme kolunun kilitleme valfına yerleştirin. Bayonet kilidi sağa doğru
döndürerek kilitleyin.
Yıkama
Döşeme yıkama başlığı kullanıldığında, bunu doğrudan vakum
hortumunun tutamağına bağlayın.
Püskürtme kolunu yukarıda açıklandığı gibi bağlayın.
GB
Spray extraction (shampooing)
Connect the spray tube using the quick coupling on the unit.
To do this, grasp the connector. Insert it with light pressure into the
quick coupling of the intake neck until it audibly latches in place.
Connect the telescopic tube with the appropriate side to the handle
of the suction hose and connect the spray extraction nozzle to the
telescopic tube.
Fasten the two retaining clips for the spray tube to the telescopic
tube. Clip the spray tube into the retainer clips.
Latch the spray lever on the handle.
Do so by pushing the plastic ribs on the spray lever into the recess on
the handle. Make sure the spray lever is correctly locked (see marking).
Close the spray tube of the extraction cleaning nozzle using the
quick coupling on the handle.
Do this by grasping the free end of the spray tube of the spray extrac-
tion nozzle. Place this on the stop valve of the spray lever. Lock it by
turning the bayonet catch to the right.
If using the upholstery spray nozzle, connect this directly to the
handle of the suction hose.
Connect the spray lever as described above.
»click«
