Daikin PGDK [20/236] Mounting the product

Mounting

FA PG - 06/2019 - 008.15 442 99_02 - EN

5.2 Mounting the product

5.2.1 Mounting the product to a module manifold

1. Remove the insulation.

2. Screw the pump assembly to module manifold.

3. Screw the pipes of the heating circuit to the top connections (no

mechanical stress).

4. Fit the complete insulation.

5.2.2 Wall mounting

NOTICE

MECHANICAL LOADS AND STRESS

• Verify that the product is not subjected to mechanical loads and stress when

connecting the product.

• If necessary, install a corrugated pipe compensator to compensate for

mechanical stress or tension.

Failure to follow these instructions can result in equipment damage.

NOTICE

MECHANICAL LOADS AND STRESS

• Verify that the product is not subjected to mechanical loads and stress when

mounting the product to the wall.

Failure to follow these instructions can result in equipment damage.
