Einhell BT-SH 90/350 [16/92] Technical data
![Einhell BT-SH 90/350 [16/92] Technical data](/views2/1079688/page16/bg10.png)
16
GB
5. Technical data
Mains voltage: 230 V ~ 50Hz
Power input: 110 W S3 50% 15min
Idling speed: 5,300 rpm
Max. useful grinding wheel diameter: 103 mm
Grinding wheel dimensions: Ø 100 x Ø 20 x 1.2 mm
Tilting range -25° - +25°
Carbide-tipped saw blade
Ø 16-32 mm x Ø 90-350 mm
Protection class: II / 쓑
Protection type: IP 20
Weight: 4.8 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level 89.4 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 100.4 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
S3 50%: Intermittent mode, no start-up, no braking
(cycle duration 15 minutes). In intermittent mode, the
percentage load factor (50%) is always quoted so
that the heat generated during this period can be
dissipated during breaks in operation by convective
cooling. Intermittent mode consists of the on time
and the cooling breaks, known as the duty cycle.
The period of consideration is 15 minutes. 50% load
factor means that the electric tool can be operated
for 7.5 minutes at the rated performance, followed by
a cooling phase of 7.5 minutes.
6. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
6.1 Assembly
6.1.1 Fitting the safety glass (Fig. 4-5 / Item 9)
Fit the safety glass (9) as shown in Figure 4-5. The
safety glass (9) must be pulled down at all times
during operation to protect your eyes from injury from
pieces of carbide metal and sparks being flung out of
the equipment.
6.1.2 Fitting the handle (Fig. 6-7 / Item 7)
Fit the handle (7) as shown in Figure 6-7.
6.1.3 Fastening
Bolt the machine securely to the surface using the
holes in the base plate (1).
6.2 Inserting saw blades
Move the motor (5) to its rear position using the
handle (7) and set the tilt angle to 0° (see also
6.3) (Fig. 8).
For small diameters slide the motor (5) on the
base plate (1) to the rear by undoing the four
Allen screws (A) on the motor holder (Fig. 2).
When the motor (5) is in the required position,
tighten the Allen screws (A) again. For medium
sized saw blade diameters the motor (5) should
be positioned in around the center, for large
diameter saw blades it should be right at the
front of the base plate (1) (Fig. 9 – 11).
Undo the locking screw (3) on the mounting arm
(2) using the pin (C) (Fig. 8).
Undo the star handle nut (12), washer (D), spring
(E) and clamping flange (F) from the mounting
arm (2) and secure the saw blade to the
mounting arm (2) using these parts (Fig. 12). The
cutting angles of the saw blade must point to the
right at the grinding point.
Align the saw blade so that the cutting angle of
the teeth is parallel to the grinding wheel (10)
and the distance between the two is approx. 15
mm. Secure the saw blade in this position by
tightening the locking screw (3) using the pin (C).
Set up the saw blade support (11) using the
Allen screw (G) and the screw connection on the
underside of the saw blade support (11) so that
the saw blade is at a 90° angle to the grinding
wheel (10) and rests on the saw blade support
Anleitung_BT_SH_90_350_SPK7:_ 21.09.2009 9:20 Uhr Seite 16
