4 | Operation
User reference guide
13
CHYHBH05+08AF + EHYKOMB33AA
Daikin Altherma R Hybrid
4P471762-1B – 2020.10
To go to the menu structure
1 From a home page, press .
Result: The menu structure is displayed.
1
>
>
>
Select
Scroll
Set time/date
Holiday
Quiet mode
Select schedules
Information
Auto
To navigate in the menu structure
Use , , , , and .
4.3.3 Turning ON/OFF controls
About turning ON/OFF controls
Before you can control… You have to turn ON…
Room temperature Room temperature control (Room)
Main (+ additional) leaving water
temperature
Main (+ additional) leaving water
temperature control (LWT main and
LWT add)
Main and additional leaving water
temperature control are always turned
ON or OFF together.
DHWtank temperature Domestic hot water control (Tank)
Instant DHW temperature Instant domestic hot water control
(DHW)
If you turn ON… Then…
Room temperature control Main (+ additional) leaving water
temperature control is automatically
turned ON.
Main (+ additional) leaving water
temperature control
Room temperature control is NOT
automatically turned ON.
If you turn OFF… Then…
Room temperature control Main (+ additional) leaving water
temperature control is NOT
automatically turned OFF.
Main (+ additional) leaving water
temperature control
Room temperature control is
automatically turned OFF.
To check if a control is turned ON or OFF
1 Go to the home page of the control. Example: Room temperature home page
(Room).
2 Check if the LED is ON or OFF. Note: If the control is turned OFF, OFF is also
displayed on the screen.
