4 | Operation
User reference guide
15
CHYHBH05+08AF + EHYKOMB33AA
Daikin Altherma R Hybrid
4P471762-1B – 2020.10
Typical additional leaving water temperature home page:
User profile = Basic User profile = Detailed
15:20
45°C
Desired temperature
LWT add
Mon
15:20
45°C
17:30
Mon
Mon
LWT add
Desired temperature
2 Check the following:
If… Then the temperature control is…
Main zone Additional zone (if
any)
Room temperature is listed
under:
[6.1]: > Information >
Sensor information
Room thermostat
control.
Go to next step to
check if leaving water
setpoint and room
temperature setpoint
are linked.
External room
thermostat control.
Thermostat main A is listed
under:
[6.5]: > Information >
Actuators
External room thermostat control.
3 Only for room thermostat control: Go to the main leaving water temperature
home page (LWT main) and check the following:
Is displayed next to
the setpoint?
Then leaving water setpoint and room
temperature setpoint are…
Yes NOT linked.
You can set the leaving water setpoint on the home
page.
No Linked by their preset values. You can set the preset
values in the menu structure.
4.4.2 Room thermostat control - About room thermostat control
Room thermostat control means that you control the following:
▪ Room temperature of the main zone
▪ Leaving water temperature of the main zone
Room temperature of the main zone
To control the room temperature of the main zone, you can do the following:
You can… Location
Read out the actual and desired room temperature. Room temperature home
page
Temporarily overrule the room temperature
schedule.
