4 | Operation
User reference guide
16
CHYHBH05+08AF + EHYKOMB33AA
Daikin Altherma R Hybrid
4P471762-1B – 2020.10
You can… Location
Change the mode from scheduled to preset value.
If you do this, you also have to define (in the menu
structure):
▪ Preset values
▪ Overrule period (Temperature lock)
Room temperature home
page if user profile =
Detailed
Select which room temperature schedule you want to
use.
Menu structure
Program schedules.
Define preset values that are used by the room
temperature schedule, and when you change the
mode from scheduled to preset value.
See also:
▪ "4.4.3 Room thermostat control - Using the room temperature home
pages"[416]
▪ "To set the overrule period"[419]
▪ "4.7Preset values and schedules"[434]
Leaving water temperature of the main zone
To control the leaving water temperature of the main zone, you can do the
following:
You can… Location
Read out the desired leaving water temperature. Leaving water
temperature home page
(main)
Adjust the leaving water temperature.
Condition: Leaving water setpoint is NOT linked with
the room temperature setpoint.
Only change this if the desired room temperature
cannot be reached.
Define preset values.
Condition: Leaving water setpoint is linked with the
room temperature setpoint.
Only change this if the desired room temperature
cannot be reached.
Menu structure
See also:
▪ "4.4.4 Room thermostat control - Using the leaving water temperature home
pages"[420]
▪ "4.7Preset values and schedules"[434]
4.4.3 Room thermostat control - Using the room temperature home pages
Typical room temperature home pages
Depending on the user profile, the user interface gives you either a basic or a
detailed home page. To set the user profile, refer to "4.6.6Configuring user profile
and home pages"[432].
