Daikin EHYKOMB33AA3 [41/44] Technical data
![Daikin EHYKOMB33AA3 [41/44] Technical data](/views2/1798425/page41/bg29.png)
14 Technical data
Installation and operation manual
41
EHYKOMB33A
Daikin Altherma hybrid heat pump – gas boiler module
4P353067-1K – 2020.10
Country Country code
(EN437)
Gas category Default setting After conversion to
G25
After conversion to
G31
Czech Republic CZ II
2H3P
G20 (20mbar) — G31 (37mbar)
Germany DE II
2ELL3P
G20 (20mbar) G25 (20mbar) G31 (50mbar)
Denmark DK I
2H
G20 (20mbar) — —
Spain ES II
2H3P
G20 (20mbar) — G31 (37mbar)
France FR II
2Esi3P
G20/G25 (20/25mbar) — G31 (37mbar)
United Kingdom GB II
2H3P
G20 (20mbar) — G31 (37mbar)
Greece GR II
2H3P
G20 (20mbar) — G31 (37mbar)
Croatia HR II
2H3P
G20 (20mbar) — G31 (37mbar)
Hungary HU I
2H
G20 (25mbar) — —
Ireland IE II
2H3P
G20 (20mbar) — G31 (37mbar)
Italy IT II
2H3P
G20 (20mbar) — G31 (37mbar)
Lithuania LT II
2H3P
G20 (20mbar) — G31 (37mbar)
Latvia LV I
2H
G20 (20mbar) — —
Malta MT I
3P
— — G31 (30mbar)
Poland PL II
2E3P
G20 (20mbar) — G31 (37mbar)
Portugal PT II
2H3P
G20 (20mbar) — G31 (37mbar)
Slovenia SI II
2H3P
G20 (20mbar) — G31 (37mbar)
Slovakia SK II
2H3P
G20 (20mbar) — G31 (37mbar,
50mbar)
Romania RO II
2H3P
G20 (20mbar) — G31 (30mbar)
Turkey TR I
2H
G20 (20mbar) — —
Ukraine UA II
2H
G20 (20mbar) — —
