4 About the box
Installation and operation manual
8
EHYKOMB33A
Daikin Altherma hybrid heat pump – gas boiler module
4P353067-1K – 2020.10
4 About the box
4.1 Gas boiler
4.1.1 To unpack the gas boiler
Before unpacking, move the gas boiler as close as possible to its
installation position.
1
2
WARNING
Tear apart and throw away plastic packaging bags so that
nobody, especially children, can play with them. Possible
risk: suffocation.
4.1.2 To remove the accessories from the gas
boiler
1 Remove the accessories.
a
b
c
a b c
a Mounting strip
b Condensate trap
c Installation and operation manual
