Daikin Altherma Low Temperature • Outdoor units • ERLQ011-016BAW1
Heating Daikin Altherma
126
6 Wiring diagram
6 - 1 Wiring diagram
8
6
2TW59586-1A
ERLQ011-016BW1
A1P Printed circuit board
A2P Printed circuit board (INV)
A3P Printed circuit board (Noise filter)
BS1BS4 Push button switch
C1C4 Capacitor
DS1 DIP switch
E1H Bottomplate heater
E1HC Crankcase heater
F1U Fuse (T 31.5A 500V)
F2U Fuse (T 31.5A 500V)
F3U Fuse (T 6.3A/250V)
F4U Fuse (T 6.3A/250V)
F5U Fuse (T 6.3A/250V)
F6U Fuse (T 6.3A/250V)
F7U Fuse (T 5.0A/250V)
F8U, F9U Fuse (F 1.0A/250V)
HAP (A1P) Light emitting diode (service monitor green)
HAP (A2P) Light emitting diode (service monitor green)
H17P (A1P) Pilot lamp (service monitor-orange)
K1M - K2M Magnetic contactor
K1R (A1P) Magnetic relay (Y1S)
K1R (A2P) Magnetic relay
K2R (A1P) Magnetic relay (Y2S)
K3R (A1P) Magnetic relay (E1HC)
L1R L3R Reactor
L4R Reactor (For outdoor fan motor)
M1C Motor (Compressor)
M1F Motor (Fan) (upper)
M2F Motor (Fan) (lower)
PS Switching power supply
R1 R4 Resistor
R1T Thermistor (Air)
R2T Thermistor (Discharge)
R3T Thermistor (Suction)
R4T Thermistor (Heat exchanger)
R5T Thermistor (heat exchanger middle)
R6T Thermistor (Liquid)
R7T Thermistor (Fin)
S1NPH Pressure sensor
S1PH Pressure switch (High)
V1R V2R Power module
V3R Diode module
X1M Terminal strip
Y1E Electronic expansion valve
Y1S Solenoid valve (4 way valve)
Y3S Solenoid valve
Z1CZ9C Noise filter
Z1FZ4F Noise filter
Q1DI Earth leakage circuit breaker
Optional connector
X6A Connector
X77A Connector
X1Y Connector
Notes:
1 This wiring diagram only applies to the outdoor unit
2 L: Live N:Neutral g: Field wiring
3 D : Terminal strip F : Connector T : Connection R : Protective earth (screw)
: Relay connector p : Noiseless earth G : Terminal
4 Refer to the option manual, for connecting wiring to x6A.
5 Refer to the ’’Wiring diagram sticker’’ (on back of front plate) on how to use BS1 BS4 and DS1 switch.
6 Do not operate the unit by short-circuiting protection device S1PH
7 Colors: BLK: black, RED: red, BLU: blue, WHT: white, YLW: yellow, ORG: orange, BRN: brown, GRN: green
8 Confirm the method of setting the selector switches by service. When the unit is shipped by factory all switches are set to be off.
Indoor
Outdoor
(Note 4)
(Front)
El. comp. Assy
Position of
compressor
terminal
Option
Wiring
dependent on
model
Power supply
3N
400V
50Hz
101727_BW_EN_004_464_IC.pdf 130 9/06/2010 14:54:11
