13
Daikin
Refrigeration
Range
Product range overview - Daikin 14
Commercial condensing units 16
Daikin Uniblock 16
Daikin Bi-block 18
Daikin Wineblock 21
Condensing units 26
JEHCCU-CM1/3 32
JEHSCU-CM1/3 33
JEHCCU-CL1/JEHSCU-CL3 34
Mini-ZEAS 35
LRMEQ-BY1
ZEAS 36
LREQ-BY1
Conveni-Pack 44
LRYEQ-AY
Indoor units and Biddle air curtains
for connection to Conveni-Pack 46
Booster unit 50
LCBKQ-AV1
Packs and Racks 51
Options for refrigeration
Options ZEAS and Conveni-Pack 53
For latest data, please consult my.daikin.eu
