24
Options
Monoblock, Biblock and Wineblock
Options Monoblock units
Option code
Medium temperature applications Low temperature applications
LMSMD LMCMD LMSLN LMCLN
Electronic control panel (MIR 90) D.CNT CTR
No Yes No
Cable for door switch connection D.MIC.POR
Yes (only in combination
with D.CNTR.CTR option)
No
Yes (only in combination
with D.CNTR.CTR option)
No
Remote control panel (5 m cable length) D.PAN.SNG
Yes (only in combination
with D.CNTR.CTR option)
No
Yes (only in combination
with D.CNTR.CTR option)
No
Common remote control panel for multiple units D.PAN.MUL
Yes (only in combination
with D.CNTR.CTR option)
Yes
Yes (only in combination
with D.CNTR.CTR option)
Longer remote control panel cable (till 10 m) D.CAV PRM 10 mt
Yes (only in combination
with D.CNTR.CTR option)
Yes
Yes (only in combination
with D.CNTR.CTR option)
Longer remote control panel cable (till 15 m) D.CAV PRM 15 mt
Yes (only in combination
with D.CNTR.CTR option)
Yes
Yes (only in combination
with D.CNTR.CTR option)
winter kit 1 full: Condenser fan pressure switch
+ Compressor crankcase heater + Supplemental
solenoid valve on the discharge line
D.PRS VNT + D.RES CAR +
D.SOL.SBR
(cap ≥ 300: included)
(cap ≥ 300: included)
Winter kit 2 basic: Condenser fan speed regulator
(temperature controlled)
D.VVE.TER No only for 300 No No
Winter kit 2 full: Condenser fan speed regulator
(temperature controlled) + Compressor crankcase
heater + Supplemental solenoid valve on the
discharge line
D.VVE.TER + D.RES CAR +
D.SOL.SBR
(cap ≥ 200: included)
(cap ≥ 300: included)
(cap ≥ 300: included)
(cap ≥ 300: included)
Winter kit 3 basic: Condenser fan speed regulator
(Pressure controlled)
D.VVE.PRS No only for 300 No No
Winter kit 3 full: Condenser fan speed regulator
(pressure controlled) + Compressor crankcase heater
+ Supplemental solenoid valve on the discharge line
D.VVE.PRS + D.RES CAR +
D.SOL.SBR
(cap ≥ 200: included)
(cap ≥ 300: included)
(cap ≥ 300: included)
(cap ≥ 300: included)
Anti-corrosion treatment (cataphoresis) on
condenser coil
D.FRS CND
Anti-corrosion treatment (cataphoresis) on
evaporator coil
D.FRS EVP
Voltage monitor D.MON TEN
Water-cooled condenser (water from net) with
pressure controlled water valve
D.CON ACQ
switchboard heater D.QUA.RIS
Only for cap ≥ 060
Only for cap ≥ 060
Centrifugal fan kit D.VNT.CEN
Only for cap ≥ 060
Only for cap ≥ 060
Serial output D.KIT.SUP
Options Biblock units
Option code
Medium temperature applications Low temperature applications
SB.LBTMD SB.LBCMD SB.LBTLN SB.LBCLN
Common remote control panel for multiple units D.PAN.MUL No
No
Longer remote control panel cable (till 10 m) D.CAV PRM 10 mt
Longer remote control panel cable (till 15 m) D.CAV PRM 15 mt
Fixed calibration high pressure switch AR D.PRS HPF Only Cap ≥ 100 Only Cap ≥ 100 Only Cap ≥ 172 Only Cap ≥ 172
Winter kit 2 basic: Condenser fan speed regulator
(temperature controlled)
D.VVE.TER
Anti-corrosion treatment (cataphoresis) on
condenser coil
D.FRS CND
Anti-corrosion treatment (cataphoresis) on
evaporator coil
D.FRS EVP
Voltage monitor D.MON TEN
Water-cooled condenser (water from net) with
pressure controlled water valve
D.CON ACQ
switchboard heater D.QUA.RIS
Serial output D.KIT.SUP
Liquid line solenoid valve D.SOL.LIQ No
No
Options Wineblock units
(mono- as well as biblock models)
Options LMSWHD
SB.LBCWHD
SB.LBWWHD
Anti-corrosion treatment (cataphoresis) on
condenser coil
D.FRS CND
Anti-corrosion treatment (cataphoresis) on
evaporator coil
D.FRS EVP
Voltage monitor D.MON TEN
Water-cooled condenser (water from net) with
pressure controlled water valve
D.CON ACQ
Serial output D.KIT SUP
Winter kit 2 basic: Condenser fan speed regulator
(temperature controlled)
D.VVE.TER
Winter kit 3 basic: Condenser fan speed regulator
(pressure controlled)
D.VVE.PRS
