15
Model Product name Capacity (kW) 0 2 5 10 25 50 100 150 300 450
Commercial
condensing units
with reciprocating
technology
CCU
JEHCCU-M1/M3/L1/L3
JEHCCU-CM1/CM3
Commercial
condensing units
with scroll technology
SCU
JEHSCU-M1/M3/L3
JEHSCU-CM1/CM3
Small inverter
condensing unit
for commercial
refrigeration
Mini-ZEAS
LRMEQ-BY1
Inverter
condensing unit
for commercial
refrigeration
ZEAS
LREQ-BY1
Multi ZEAS
LREQ-BY1R
Integrated solution
for chilling, freezing
and comfort cooling
and heating
Conveni-Pack
LRYEQ-AY
Booster unit to allow
both ZEAS and
Conveni-Pack
freezing applications
Booster unit
LCBKQ-AV1
Packs & Racks
MT
LT
Screw
LT
Screw
rack LT
Chillers
MT
LT
Chilling Freezing HeatingAir conditioning
Packs: Units with one compressor
Racks: Units with 2 or more compressors
