Bomann MWG 2211 U CB [41/50] Information plates and symbols on the product
![Bomann MWG 2211 U CB [41/50] Information plates and symbols on the product](/views2/1080209/page41/bg29.png)
41
Information Plates and Symbols on the Product
On the top of the microwave there is a hazard symbol with the following text:
WARNING-
MICROWAVE ENERGY-DO
NOT REMOVE THIS COVER.
CAUTION: HOT SURFACE
During operation the temperature of the exposed surface may be very hot. Danger of burns!
On the back of the microwave there is an information plate with the following text:
WARNING
• MICROWAVE AND HIGH VOLTAGE INSIDE. BE SURE NOT TO REMOVE THE ENCLOSURE.
• THIS APPLIANCE IS EQUIPPED WITH A GROUNDED PLUG FOR YOUR PROTECTION AGAINST POS-
SIBLE SHOCK HAZARDS AND SHOULD BE CONNECTED TO A PROPERLY GROUNDED OUTLET.
• THIS DEVICE IS TO BE SERVICED ONLY BY PROPERLY QUALIFIED SERVICE PERSONNEL.
• DISCONNECT POWER PLUG BEFORE SERVICING. REMOVAL OF THE ENCLOSURE WITH PRODUCT
ENERGIZED COULD EXPOSE SERVICEMEN TO HAZARDOUS HIGH VOLTAGE POTENTIAL.
Overview of the Components
1 Control panel
2 Grill
3 Drive axle
4 Guide ring
5 Turntable
6 Door latches
7 Viewing window
Switches on the control panel
DEFROST BY W.T Defrosting according to weight
CLOCK/PRE-SET
Clock: In combination with the turning knob for
setting the clock or a starting time
DEFROST BY TIME Defrosting according to time
QUICK START/START - Starting the function
- Quick start of the microwave (always
+60 seconds at 100% power)
MICRO./GRILL/COMBI.
Microwave: Select power setting of the microwave
Grill: For roasting and scalloping
Grill/Combi: Grill and microwave operate in turns
CANCEL/STOP
Stop: Press once to stop cooking
Delete: Press twice to delete function
Lock: Press and hold the CANCEL/STOP
button for 3 seconds in order to lock
(child-proof lock) or unlock the control
panel
AUTO MENU Selection of the automatic programs
TIMER • POWER • WEIGHT
Rotary knob for setting the time, cook-
ing or defrosting time, power levels,
combinations, automatic programs or
weights
Symbols on the control panel
Symbol
Meaning/
function
Symbol
Meaning/
function
Microwave
Child-proof lock
activated
Defrosting Auto function
Grill Weight in grams
Microwave +
grill
Programmed
Start
Power high/low
Avoiding the Danger of Fire when Installing as
a Bottom-Mounted Device
If you would like to install the microwave as a bottom-mounted
device on a cupboard or shelf, for example, please note the infor-
mation in the section “Installation Instructions for Bottom-Mounted
Devices”.
• Do not remove the feet on the underside of the device.
• Please use only the attachment materials supplied if you want
to install the microwave under a cupboard.
• Maintain the following distances between the sides of the
device and the furniture when installing the microwave:
