75
Warning:
► If food is being heated or cooked in combustible materials,
such as plastic or paper containers, the microwave oven
should be checked frequently due to the risk of re.
► If smoke is produced, turn the device off and remove the plug.
Keep the door closed in order to suffocate any ames.
► The contents of babies‘ bottles and jars of baby food must be
stirred or shaken and the temperature checked before use.
There is a danger of burns.
► Use pot cloths or oven gloves to remove containers. RISK OF
BURNS!
► Food with a shell or skin, such as eggs, sausages, sealed
jars etc. must not be heated up in the microwave as they may
explode even when heating by the microwaves is nished.
Delay in boiling:
During boiling, particularly during the reheating of liquids (water),
it may happen that the boiling temperature has been reached but
the typical bubbles have not yet started to rise. The liquid does
not boil evenly. When the vessel is removed this so-called delay
in boiling may result in the sudden formation of bubbles when
the vessel is knocked, causing the water to boil over. There is a
serious danger of burns! In order to achieve even boiling, please
place a glass rod or similar item, but nothing metallic, in the ves-
sel.
• Any dirt on the door frame/door seal and neighbouring parts
must be carefully cleaned with a damp cloth.
• Clean the microwave oven regularly and remove any food
residues from the interior.
• If the machine is not clean the surface may be damaged, af-
fecting its serviceable life and possibly resulting in hazardous
situations.
• Please do not operate the device with an external timer or a
separate remote control system.
Information Plates and Symbols on the Product
On the top of the microwave there is a hazard symbol with the fol-
lowing text:
WARNING-
MICROWAVE ENERGY-DO
NOT REMOVE THIS COVER.
CAUTION: HOT SURFACE
During operation the temperature of the exposed surface may be
very hot. Danger of burns!
On the back of the microwave there is an information plate with the
following text:
WARNING
• MICROWAVE AND HIGH VOLTAGE INSIDE. BE SURE NOT
TO REMOVE THE ENCLOSURE.
• THIS APPLIANCE IS EQUIPPED WITH A GROUNDED PLUG
FOR YOUR PROTECTION AGAINST POSSIBLE SHOCK
HAZARDS AND SHOULD BE CONNECTED TO A PROPERLY
GROUNDED OUTLET.
• THIS DEVICE IS TO BE SERVICED ONLY BY PROPERLY
QUALIFIED SERVICE PERSONNEL.
• DISCONNECT POWER PLUG BEFORE SERVICING. RE-
MOVAL OF THE ENCLOSURE WITH PRODUCT ENERGIZED
COULD EXPOSE SERVICEMEN TO HAZARDOUS HIGH
VOLTAGE POTENTIAL.
Location of controls
Picture A
1 Control Panel
2 Door opener
3 Griller
4 Drive shaft
5 Lower heating element
6 Turntable ring
7 Enamelled metal plate
8 Door latch
9 Viewing window
Not shown.: Pizza stone
Picture B: Symbols on the control panel
1 Microwave
2 Convection
3 Grill
4 Defrost
5 Child-proof lock activated
6 Auto function
7 Temperature indicator
Switches on the control panel
MICROWAVE
Microwave: Select power setting of the microwave
DOUBLE GRILL/COMBI.
Grill: For roasting and scalloping
Grill/Combi: Grill, microwave and convection operate in
turns
CONVECTION
Convection: Convection without microwave operation;
select a temperature.
W.T./TIME DEFROST
Defrosting by weight or time
CLOCK/PRE-SET
Clock: In combination with the turning knob for
setting the clock or a starting time
STOP/CLEAR
Stop: Press once to stop cooking.
Delete: Press twice to delete function.
Lock: Press and hold the STOP/CLEAR button
for 3 seconds in order to lock (child-proof
lock) or unlock the control panel
START/+30Sec./CONFIRM
○ Starting the function
○ Quick start of the microwave (always
+30 seconds at 100% power)
○ Prolonging the cooking time by 30 sec-
onds during operation (except when
defrosting or using auto function)
○ Conrming a setting
TIMER●WEIGHT●AUTO MENU
Turning knob for setting the clock, cooking
time, temperature, combi modes, auto
functions or weight settings
