• Touch screen with back-light
• Small, Simple and Smart design, 86x86x13mm
• On/Off , Mode, Fan speed, Temperature setting, Swing.
• Individual control & Group control (Max 16 indoor units)
• Fahrenheit / Celsius selectable; Sensitivity ±0.5°C
• Static pressure setting.
YR-E17
• 7 Day Timer / Clock
• Large touch button with blue LCD, with back-light.
• Error display is listed in Year/Month/Date format.
• On/Off , Mode, Fan speed, Temperature setting, Swing
• Individual control & Group control (Max 16 indoor units)
• Fahrenheit / Celsius selectable; Sensitivity ±0.5°C
• Static pressure setting
YR-E16A
• Supplied with Cassette
• Oversized display with oversized buttons for easy use.
• Temperature setting of 0.5 degree increments
• Individual cassette louver control for round way cassette
• Follow and evade function for use with PB-950MB panel.
YR-HBS-01
Wireless control for Ducted system
• RE-02 Infrared receiver control for duct type indoor unit.
• Requires one YR-HD
DRAWINGS
CONTROLS
• 7 Day Timer / Clock
• Large touch button with colour LCD, with back-light.
• Error display is listed in Year/Month/Date format.
• On/Off , Mode, Fan speed, Temperature setting, Swing
• Individual control & Group control (Max 16 indoor units)
• Fahrenheit / Celsius selectable; Sensitivity ±0.5°C
• Static pressure setting
YR-E16B
- 26 -
