• Wi-Fi control
• APP Free download for Apple and Android
• Weekly timer
• Connect multiple units.
KZW-W001
• Central control (Max 32 indoor units)
• Individual control, Group control
• Large touch keys
• 7 day timer.
• Unit name & Group name free setting. Four background available (mall,
hotel, offi ce, home)
YCZ-G001
YCZ-A004
• Central control (Max 256 indoor units)
• Individual control, Group control
• 7-inch Touch colour screen
• Schedule control
• Indoor units information.
DRAWINGS
CENTRAL CONTROLS
,
HC-SA164DBT
• Central control (Max 64 indoor units)
• Individual control, Group control
• 5-inch TFT Touch colour screen,
• Weekls schedule control
• Can be connected to MRV, Smart power, Super Match and HRV.
- 27 -
