Haier ABH140K5ERG [9/28] Features and benefits
![Haier ABH090K5ERG [9/28] Features and benefits](/views2/1812951/page9/bg9.png)
Handles for easier transporting
Four handles are designed into each outdoor unit to allow
for two people to carry.
Large Fans - Low Sound Level
Lower sound level can be achieved by an industry
leading 550 mm fan and unique outlet grille. The new
grille design off ers less resistance to airfl ow and less
noise.
Haier Fan GrilleCompetitor Fan Grille
Corrosion protection
Haier evaporator adopts new generation blue aluminium
fi n which specializes in strong corrosion resistance and
super hydrophilic performance.
Blue
Corrosion protection
Corrosion protection
Corrosion protection
Blue
Corrosion protection
Corrosion protection
Blue
Corrosion protection
Blue
Corrosion protection
COMPLIANT
MINIMUM ENERGY PERFORMANCE STANDARDS
450mm
550mm
“888” digital test panel
All running parameters and error code can be checked
from the “888” digital display. Simpler operation to reduce
diagnosis time.
handle
handle
handle
handle
handle
handle
Handles
Wi-Fi
It is simple to make the Haier Smart Power System Wi-Fi compatible.
Purchase the additional accessory KZW-W001 and connect it to the
indoor unit. Then control your Haier System wherever you are by smart
phone or tablet.
The Wi-Fi module (KZW-W001) will connect to the internet via your Wi-Fi router
(Wi-fi router not supplied).
Download the Haier smart Air 2 APP. free from Apple or Android stores.
FEATURES AND BENEFITS
- 9 -
