SPECIFICATIONS

Model CJ65V3 CJ65S3

Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)

Power input 400W*

Wood: 65mm

Max. cutting depth

Mild steel: 6mm

No-load speed 0 – 3000 min

–1

3000

min

–1

Stroke 18mm

Min. cutting radius 25mm

Weight (without cord) 1.5kg

* Be sure to check the nameplate on product as it is subject to change by areas.

STANDARD ACCESSORIES

(1) Blade No.31 ................................................................. 1

For cutting thick lumber

(2) Splinter guard ............................................................. 1

(3) Chip cover ................................................................... 1

(4) Hexagonal bar wrench ............................................... 1

Standard accessories are subject to change without

notice.

OPTIONAL ACCESSORIES (sold separately)

(1) Blades, No.1 – No.6, 31*

* No.31 Blade is a standard accessory.

(2) Guide

Optional accessories are subject to change without notice.

APPLICATIONS

䡬 Cutting various lumber and pocket cutting

䡬 Cutting mild steel plate, aluminum plate, and copper

plate

䡬 Cutting synthetic resins, such as phenol resin and

vinyl chloride

䡬 Cutting thin and soft construction materials

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position. If

the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, which could cause a serious

accident.

3. Extension cord

When the work area is removed from the power

source, use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

MOUNTING THE BLADE

1. Use the accessory hexagonal bar wrench to loosen

the blade set screws on the blade holder, as shown in

Fig. 1(a).

2. Holding the blade with its cutting edge facing the

front, insert the mounting portion of the blade into

the plunger groove until it touches the bottom of the

groove.

3. As shown in Fig. 1(b), firmly clamp the side screw.

CAUTION

䡬 Loosened set screws may cause the blade to be

damaged. Always ensure that the set screws are

securely tightened. Always ensure that the plunger

groove is clean and clear of sawdust to ensure proper

blade mounting and set screw clamping.

4. Storing the hexagonal bar wrench

(1) Insert in a hole on the side of the main unit with

holding the short side horizontally as shown in

Fig. 2.

(2) Rotate with the hexagonal bar wrench inserted and

secure as shown in Fig. 2.

ADJUSTING THE GUIDE ROLLER

The guide roller, shown in Fig. 3, is employed to prevent

the blade from snapping. Prior to use, adjust guide roller

in accordance with the following procedures:

(1) Loosen the holder set screw with the accessory

hexagonal bar wrench.

(2) Gently slide the guide roller until the roller groove

lightly touches the back of the blade.

NOTE

On delivery from the factory, there is a gap of about

3mm between the roller and blade.

(3) Firmly tighten the holder set screw.

CAUTION

䡬 The guide roller can be used only for Blades that

have a straight line on the rear that is longer than

50mm. (Fig. 4A and 4B) When using other types

of blades (Fig. 4C), slide the guide roller in

backwards so that the guide roller does not contact

the blade.

䡬 When cutting thick boards or performing

continuous cutting operations, use the blade

shown in the Fig. 4A, 4B and be sure to set the

guide roller.

CHIP COVER POSITIONING

1. Chip cover

Use the chip cover to reduce flying of cut particles

and to easily operate the saw.
