9
English
䡬 Make absolutely sure that you cut slowly while
holding the body firmly. If you apply any
unreasonable force to the saw blade during the
cutting operation, the blade can easily be damaged.
SELECTION OF BLADES
To ensure maximum operating efficiency and results, it
is very important to select the appropriate blade best
suited to the type and thickness of the material to be cut.
NOTE:
䡬 Dimensions of the workpiece mentioned in the table
represent the dimensions when the mounting
position of the base is set nearest to the body of
the reciprocating saw. Caution must be exercised
since dimensions of the workpiece will become
smaller if the base is mounted far away from the
body of the reciprocating saw.
1. Selection of HCS blades
The blade number of HCS blades in Table 1 is
engraved in the vicinity of the mounting position
of each blade. Select appropriate blades by referring
to Tables 1 and 4 below.
Table 1: HCS blades
NOTE
No. 1 – No. 96 HCS blades are sold separately as
optional accessories.
2. Selection of BI-METAL blades
The BI-METAL blade numbers in Table 2 are
described on the packages of special accessories.
Select appropriate blades by referring to Table 2
and 4 below.
Table 2: Bl-METAL blades
NOTE
Nos. 101 – No. 132 Bl-METAL blades are sold separately
as optional accessories.
Table 3: Curved blades
3. Selection of blades for other materials
Table 4
Blade Thickness
No.
Uses
(mm)
No. 1 For cutting steel pipe less than
105 mm in diameter
2.5 – 6
No. 2 For cutting steel pipe less than
30 mm in diameter
2.5 – 6
No. 3 For cutting steel pipe less than
30 mm in diameter
Below 3.5
No. 4
For cutting and roughing lumber
50 – 70
No. 5
For cutting and roughing lumber
Below 30
No. 8
For cutting vinyl chloride pipe less
than 135 mm in diameter
2.5 – 15
For cutting and roughing lumber
Below 105
No. 9 For cutting mild steel pipe less
than 130 mm in diameter when 2.5 – 6
used with cut off guide
No. 95 For cutting stainless steel pipe
less than 105 mm in diameter
Below 2.5
No. 96 For cutting stainless steel pipe
less than 30 mm in diameter
Below 2.5
Blade Thickness
No.
Uses
(mm)
No. 101
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 102
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 103
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 104
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 105
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
No. 106
For cutting steel and stainless pipes
less than 130 mm in outer diameter
2.5 – 6
No. 107
For cutting steel and stainless pipes
less than 60 mm in outer diameter
Below 3.5
No. 108
For cutting steel and stainless pipes
less than 130 mm in outer diameter
Below 3.5
No. 121
For cutting and roughing lumber 300
No. 131
All purposes —
No. 132
All purposes —
Blade Thickness
No.
Uses
(mm)
No. 341
For cutting steel and stainless pipes
less than 60 mm in outer diameter
2.5 – 6
Material Material Thickness
Blade No.
to be cut quality (mm)
Iron plate Mild steel 2.5 – 19 No. 1, 2, 101,
plate 102, 103, 104,
105, 106, 131,
132
Below 3.5 No. 3, 107,
108
Nonferrous Aluminium, 5 – 20 No. 1, 2, 101,
metal Copper and 102, 103, 104,
Brass 105, 106, 131,
132
Below 5 No. 3, 107,
108
