SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)
Power Input 1150 W*
Capacity Mild Steel Pipe: O.D. 130 mm
Vinyl Chloride Pipe: O.D. 130 mm
Wood: Depth 300 mm
Mild Steel Plate: Thickness 19 mm
No-Load Speed 0 – 3000min
–1
Stroke 32 mm
Weight (without cord) 4.4 kg
STANDARD ACCESSORIES
(1) Blade (No. 341) ......................................................... 1
(2) Case ............................................................................. 1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
(1) No. 1 Blade (11) No. 102 Blade
(2) No. 2 Blade (12) No. 103 Blade
(3) No. 3 Blade (13) No. 104 Blade
(4) No. 4 Blade (14) No. 105 Blade
(5) No. 5 Blade (15) No. 106 Blade
(6) No. 8 Blade (16) No. 107 Blade
(7) No. 9 Blade (17) No. 108 Blade
(8) No. 95 Blade (18) No. 121 Blade
(9) No. 96 Blade (19) No. 131 Blade
(10) No. 101 Blade (20) No. 132 Blade
䡬 (1) – (9) : HCS Blades (HCS : High speed Carbon
Steel)
䡬 (10) – (20) : Bl-METAL Blades
Refer to Table 1, 2 and 3 for use of the blades.
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Cutting pipe and angle steel.
䡬 Cutting various lumbers.
䡬 Cutting mild steel plates, aluminum plates, and
copper plates.
䡬 Cutting synthetic resins, such as phenol resin and
vinyl chloride.
For details refer to the section entitled “SELECTION OF
BLADES”.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirement specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause
a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Dust produced in operation
The dust produced in normal operation may affect
the operator’s health. To wear a dust mask is
recommended.
5. Mounting the blade
This unit employs a detachable mechanism that
enables mounting and removal of saw blades
without the use of a wrench or other tools.
(1) Turn on and off the switching trigger several times
so that the lever can jump out of the front cover
completely. Thereafter, turn off the switch and
unplug the power cord. (Fig. 1)
CAUTION
Be absolutely sure to keep the switch turned off
and the power cord unplugged to prevent any
accident.
(2) Push the lever in the direction of the arrow mark
shown in Fig. 2 marked on the lever. (Fig. 2)
(3) Insert the saw blade all the way into the small slit
of the plunger tip with the lever pushing. You can
mount this blade either in the upward or downward
direction. (Fig. 3, Fig. 4)
(4) When you release the lever, the spring force will
return the lever to the correct position automatically.
(Fig. 5)
PRECAUTIONS ON USING RECIPROCATING
SAW
Prior to cutting into walls, ceilings or floors, ensure
there are no electric cables or conduits inside.
