Panasonic WH-MXF12D3E8 [103/118] Disassembly and assembly instructions
![Panasonic WH-MXF12D3E8 [103/118] Disassembly and assembly instructions](/views2/1832911/page103/bg67.png)
103
17. Disassembly and Assembly Instructions
WARNING
High Voltage are generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged
sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks.
WARNING
Be sure to switch off all the power supply before performing each of the below action.
17.1 To Remove The Cabinet Front Plate
17.2 To Remove The Cabinet Top Plate
