16.2 Relationship Between The Condition Of The Mono bloc Unit And
Pressure And Electric Current
Heating Mode
Condition of the Mono bloc Unit
Low Pressure High Pressure
Electric current during
operation
Water leakage or insufficient water flow
rate in the system
Ò Ò Ò
Excessive amount of refrigerant
Ò Ò Ò
Inefficient compression
Ò Ô Ô
Insufficient refrigerant
(gas leakage)
Ô Ô Ô
Mono bloc unit (refrigerant system) heat
exchange deficiency
Ô Ô Ô
Clogged expansion valve or Strainer
Ô Ò Ò
• Carry out the measurements of pressure, electric current, and temperature fifteen minutes after an operation is
started.
