7
2.2 WH-MXF12D9E8
Item Unit Refrigerant System
Performance Test Condition EN14511
Heating Condition (Ambient/Water) A7W35 A2W35
Heating Capacity kW 12.00 12.00
BTU/h 40900 40900
kcal/h 10320 10320
COP W/W 4.67 3.40
kcal/hW 4.02 2.92
Air Flow m
3
/min (ft
3
/min) 80.0 (2830)
Refrigeration Control Device Expansion Valve
Refrigeration Oil cm
3
FV50S (1200)
Refrigerant (R410A) kg (oz) 2.30 (81.2)
Pipe Diameter Liquid mm (inch) 9.52 (3/8)
Gas mm (inch) 15.88 (5/8)
Compressor Type Hermetic Motor
Motor Type Brushless (4-poles)
Rated Output kW 4.30
Fan Type Propeller Fan
Material PP
Motor Type Induction (8-poles)
Input Power W -
Output Power W 60
Fan Speed rpm 510 (Top Fan) 550 (Bottom Fan)
Heat Exchanger Fin material Aluminium (Pre Coat)
Fin Type Corrugated Fin
Row x Stage x FPI 2 x 51 x 18
Size (W x H x L) mm 881.5 x 1295.4 x 44
Item Unit Mono bloc Unit
Dimension Height mm (inch) 1410 (55-1/2)
Width mm (inch) 1283 (50-1/2)
Depth mm (inch) 320 (12-19/32)
Net Weight kg (lbs) 159 (351)
Noise Level dB-A 50
Power Level dB 67
Power Source (Phase, Voltage, Cycle) ø Three
V 400
Hz 50
Input Power kW 2.57 3.53
Maximum Input Power For Mono bloc Unit kW 7.91
Power Supply 1: Phase (ø) / Max.Current (A) / Max. Input Power (W) Three / 11.9 / 7.91k
Power Supply 2: Phase (ø) / Max.Current (A) / Max. Input Power (W) Single / 13.0 / 3.00k
Power Supply 3: Phase (ø) / Max.Current (A) / Max. Input Power (W) Three / 9.00k
Starting Current A 3.9
Running Current A 3.9 5.3
Maximum Current For Mono bloc Unit A 11.9
Power Factor % 96
