8
Item Unit Mono bloc Unit
Power factor means total figure of compressor and outdoor fan motor.
Power Cord Number of core -
Length m (ft) -
Thermostat Electronic Control
Protection Device Electronic Control
Item Unit Water System
Performance Test Condition EN14511
Operation Range Outdoor Ambient °C -20 ~ 35
Water Outlet °C 25 ~ 55
Internal Pressure Differential kPa 27.5
Refrigerant Pipe Diameter Liquid
mm (inch)
9.52 (3/8)
Gas
mm (inch)
19.05 (3/4)
Water Pipe Diameter Inlet
mm (inch)
30 (1-3/16)
Outlet
mm (inch)
30 (1-3/16)
Water Drain Hose Inner Diameter
mm (inch)
15.00 (19/32)
Pump Motor Type Capacitor Run Induction Motor (5 µF)
No. of Speed 3
Input Power W 180
Hot Water Coil Type Brazed Plate
No. of Plates 60
Size (W x H x L) mm 100 x 93 x 325
Water Flow Rate l/min (m
3
/h) 34.4 (2.1)
Pressure Relief Valve Water Circuit kPa Open: 190, Close: 186 and below
Flow Switch Magnetic Lead Switch
Protection Device A Residual Current Circuit Breaker (40)
Expansion Vessel Volume I 10
MWP bar 1
Capacity of Integrated Electric Heater kW 9.00
Note:
1. Heating capacities are based on outdoor air temperature of 7°C Dry Bu b (44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb) with controlled
water inlet temperature of 30°C and water outlet temperature of 35°C.
2. Specifications are subjected to change without prior notice for further improvement.
