5
ENGLISH
– replace the battery in time;
– apply to specialized centers for further recycling of the
battery;
– avoid the power nippers circuit.
Installing or replacing the battery
in the remote control (15)
· Remove the battery compartment lid by turning it to the
position « ».
· Install a CR2025 battery strictly following the polarity.
· Install the battery compartment lid back to its place and
turn it to the position « ».
Note: - if there is an isolation insert, remove the insert.
USING THE FAN
Notes:
– the operation mode selection buttons on the control
panel (2) are sensory, you just need to touch the button
to switch the necessary operation mode on.
· Before using the unit for the first time, make sure that the
mains voltage corresponds to the unit operating voltage.
· Insert the plug into the mains socket, you will hear a
sound signal and the on/off button (12) « » indicator
will light up.
· To switch the fan on press the on/off button (7) « »
«POWER» on the control panel (2) or the button (7)
«POWER» on the RC (15). The fan will switch on at the
medium speed and the indicator (1) « » will light up.
· Select the blades rotation speed by pressing the but-
tons (8) « » on the control panel (2) or the buttons (8)
«Speed » on the RC (15):
« » – low air flow speed;
« » – medium air flow speed;
« » – high air flow speed.
· To switch the horizontal rotation operation mode on
press the button (9) « » «SWING» on the control panel
(2) or the button (9) « » «SWING» on the RC (15).
Note: - press the buttons (9) « » «SWING» again to switch
the rotation mode off and direct the air flow in the neces-
sary direction.
· Press the button (10) « » «TIMER» or the buttons
(10) «Timer » on the RC (15) to select the automatic
switch-off timer operation time, the indicators (17) will
be glowing.
· You can set the fan operation time from 1 hour to 8 hours
«1Н-2Н-4Н-6Н-7Н-8Н» (with 1 hour setting step).
· The set timer operation time is shown with the indica-
tors (17).
· To switch the timer off repeatedly press the button (10)
« » «TIMER» or the buttons (10) «Timer » on the RC
(15) until the indicators (17) go out.
· Select the air flow mode with the «MODE» button (16),
the light indicators show the selected mode:
« » – just ventilation;
« » – natural wind;
« » – sleep wind.
· To switch the fan off press the on/off button (7) « »
«POWER» on the control panel (2) or the button (7)
«POWER» on the RC (15). The fan will switch off; then
unplug it.
MAINTENANCE AND CARE
· Before cleaning the fan switch it off by pressing the
on/off button (7) « » «POWER» on the control panel
(2) or the button (7) «POWER» on the RC (15). The fan
will switch off; then unplug it.
· Do not use abrasive cleaners or solvents to clean the fan.
· Wipe the fan with a slightly damp cloth and then
wipe it dry.
· You may clean the fan blades with a vacuum cleaner
using a proper attachment.
· Do not immerse the fan into water or other liquids. Make
sure that no liquids get into the motor unit (4) of the fan
or into the base to avoid its damage and prevent risk of
electric shock.
STORAGE
· Unplug the fan and clean it.
· Pack the fan into the original package and put it away
for storage in a dry cool place away from children and
disabled persons.
DELIVERY SET
Fan – 1 pc.
Remote control – 1 pc.
Manual – 1 pc.
Warranty certificate – 1 pc.
TECHNICAL SPECIFICATIONS
Fan
Power supply: 220-240 V ~ 50-60 Hz
Rated input power: 40 W
Blades diameter: 24 cm (10”)
Remote Control
Power supply: 3 V, «СR2025» type battery (included)
RECYCLING
For environment protection do not throw out the unit and
the batteries (if included), do not discard the unit and the
batteries with usual household waste after the service
life expiration; apply to specialized centers for further
recycling.
The waste generated during the disposal of the unit is sub-
ject to mandatory collection and consequent disposal in the
prescribed manner.
For further information about recycling of this product apply
to a local municipal administration, a disposal service or to
the shop where you purchased this product.
The manufacturer preserves the right to change design,
structure and specifications not affecting general principles
of the unit operation without a preliminary notification due
to which insignificant differences between the manual and
product may be observed. If the user reveals such differ-
ences, please report them via e-mail info@coolfort.ru for
receipt of an updated manual.
Unit operating life is not less than 3 years
Guarantee
Details regarding guarantee conditions can be obtained
from the dealer from whom the appliance was purchased.
The bill of sale or receipt must be produced when making
any claim under the terms of this guarantee.
This product conforms to the EMC Directive
2014/30/EU and to the Low Voltage Directive
2014/35/EU.
