10 ENGLISH

To adjust handle D

R 650

The handle can be fitted either at the top or at the

side.

Move to the side position

: Push the sleeve

downwards, pull out the lever and insert it into the

side opening.

Move to the top position

: Pull out the lever, pull

the sleeve downwards, insert the lever and lock the

sleeve again.

R 750

The handle can be turned forwards to allow the

machine to be pulled more easily.

Push the sleeve downwards, pull out the lever, turn

it through 180° and insert it again.

Carry position E

The handle can be locked for carrying. To do this

push the handle and pull the lock. To release the

lock, press the handle briefly.

Start / Stop F

Switch the motor on and off at the switch:

Motor off.

Turn clockwise; remove blockages.

Turn anti-clockwise, return jammed spirals.

Start the spirals turning by pressing the handle.

Operation G

Insert a suitable spiral, secure the protective pipe

and secure a suitable tool.

1 Position the machine approx. 50-80 cm in

front of the opening of the pipe you wish to

clean.

Set the machine to turn clockwise at the

On/Off switch.

2 Insert the spiral approx. 500 mm into the

pipe. Press the handle. The spiral will start to

turn.

Guide the spiral only with the supplied

special safety glove.

Release the handle and push the spiral further

into the pipe.

Repeat this process until you feel resistance;

this means you have reached the blockage.

3 Pull the spiral out of the machine until the

spiral is prestressed into a bend (working

bend).

Press the handle and press the spiral against

the blockage using the working bend.

When the spiral has moved into the pipe so

far that the working bend is relieved, pull the

spiral out of the machine and form a new

working bend.

4 Repeat this process until the blockage has

been removed, then release the handle and

pull out the spiral. If it does not move easily,

press the handle and allow the spiral to turn

briefly.

If the tool becomes fastened to the

blockage, release the handle and switch the

machine to turn anti-clockwise.

Release the tool from the blockage by moving

the spiral to and fro whilst pressing the

handle.

Care and Maintenance H

Pull the mains plug before carrying out any work

on the machine.

Grease the machine with universal grease at the

two lubrication points:

Lubrication point 1: every 5 hours of service.

Lubrication point 2: every 100 hours of

service. Unscrew the left cover to access this

point.

Clean the machine at regular intervals.

Clean and preserve the spirals and tools each time

after you have used the machine. We recommend

our special

“ROWONAL” care product for this purpose.

All other servicing, maintenance and repair work

may only be carried out by an authorised

ROTHENBERGER workshop.

Replace the calmp jaws I

If the spiral no longer turns or slips, the clamp jaws

are worn and must be replaced.

1 Unscrew the right cover

2 Remove the sealing stopper. Undo the lock

nut and undo the adjusting screw until the

clamp jaw springs are no longer stressed.

3 Pull the handle upwards and hold it in this

position.Remove the clamp jaws. Press the

clamp jaws together to release them.

4 Fit new clamp jaws.
