OMM-VTS-ver.6.3 (08.2022)
www.vtsgroup.us 41
Table 32 ABB: Frequency converter - Specs
Mains Connection
Voltage and
1 phase, 200 to 240V ± 10%
power range
2.4 to 9.8 A (I
2N
)
3 phase, 200 to 240V ± 10%
2.6 to 50.8 A (I
2N
)
3 phase, 380 to 480V ± 10%
1.2 to 44.0 A (I
2N
)
Frequency
48 to 63 Hz
Motor Connection
Voltage
3-phase, from 0 to U
supply
Frequency
0 to 500 Hz
Continuous loading
I
2N
maximum continuous output current at
capability
ambient temperature of +40 ⁰C
No overload ability, derating 1% for every
additional 1 ⁰C up to 50 ⁰C
I
LD
continuous output current at max
ambient temperature of +50 ⁰C
10% overload ability for one minute every
ten minutes
Switching frequency
Default
4 kHz
Selectable
4 to 16 kHz with 4 kHz steps
Acceleration time
0.1 to 1800 s
Deceleration time
0.1 to 1800 s
Motor control method
Scalar U/f
Environmental Limits
Ambient temperature
-10 to 50 ⁰C (14 to 122 ⁰F), no frost
allowed
Altitude
Rated current available at 0 to 1000 m
Output current
(0 to 3281 ft) reduced by 1% per 100 m
(328 ft) over 1000 to 2000 m
(3281 to 6562 ft)
Relative humidity
Lower than 95% (without condensation)
Degree of protection
IP20/optional NEMA 1 enclosure
Enclosure color
NCS 1502-Y, RAL 9002, PMS 420 C
Contamination levels
IEC721-3-3
No conductive dust allowed
Transportation
Class 1C2 (chemical gases)
Class 1S2 (solid particles)
