![VTS American VENTUS AVS 230 Инструкция по инсталляции онлайн [42/60] 676431](/views2/1894744/page42/bg2a.png)
OMM-VTS-ver.6.3 (08.2022)
www.vtsgroup.us 42
Storage
Class 2C2 (chemical gases)
Class 2S2 (solid particles)
Operation
Class 3C2 (chemical gases)
Class 3S2 (solid particles)
Table 32 (cont.) ABB: Frequency converter - Specs
Product compliance
Low Voltage Directive 2006/95/EC
Machinery Directive 2006/42/ES
EMC Directive 2004/108/EC
Quality assurance system ISO 9001
Environmental system ISO 14001
UL, cUL, CE, C-Tick and GOST R approvals
RoHS compliant
Table 32 (cont.) ABB: Frequency converter - Specs
Programmable Control Connections
Two analog inputs
1 phase, 200 to 240V ± 10%
Voltage signal
Unipolar
0 (2) to 10 V, R
in
› 321 kΩ
Bipolar
-10 to 10 V, R
in
› 321 kΩ
Current signal
Unipolar
0 (4) to 20 mA, R
in
= 100 Ω
Bipolar
-20 to 20 mA, R
in
= 100 Ω
Resolution
0.10%
Accuracy
± 1%
One analog output
0 (4) to 20 mA, load < 100 Ω
Auxiliary voltage
24 V DC ± 10%, max. 200 mA
Five digital inputs
12 to 24 V DC with internal or external
supply, PNP and NPN, pulse train
0 to 16 kHz
Input impedance
2.4 kΩ
One relay output
Type
NO + NC
Maximum switching voltage
250 V AC/30 V DC
Maximum switching current
0.5 A/30 V DC; 5 A/230 V AC
Maximum continuous current
2 A rms
One digital output
Type
Transistor output
Maximum switching voltage
30 V DC
Maximum switching current
100 mA/30 V DC, short circuit
Frequency
10 Hz to 16 kHz
Resolution
1 Hz
Accuracy
0.20%
Programmable Control Connections
Cable
Shielded twisted pair, impedance 100 to
150 ohms
