Accessories
309572ZAT 31
Accessories
Scuff Guard / Protective
Cover
Use to keep hose clean and protect it from damage.
Part Description
246077 7 ft (2.1 m) braided polyester mesh.
For whip hose. Fold back over itself for
easy installation.
246805 25 ft (7.6 m) braided polyester mesh.
Fold back over itself for easy
installation.
246078 50 ft (15.2 m) braided polyester mesh
Fold back over itself for easy
installation.
246456 50 ft (15.2 m) polyethylene bag.
Inflate with air for easy installation.
25M494 Xtreme-Wrap abrasion-resistant
sleeve for 10 ft (3.0 m) whip hose
17E473 Xtreme-Wrap abrasion-resistant
sleeve for 20 ft (6.1 m) whip hose
25M493 Xtreme-Wrap abrasion-resistant
sleeve for 50 ft (15.2 m) hoses
25M495 3 ft (0.9 m) Joint Cover
