Graco Reactor 2 H-40 APH046 [4/34] Standard 2 component hose
![Graco Reactor 2 H-40 AHH145 [4/34] Standard 2 component hose](/views2/1900952/page4/bg4.png)
Power-Lock Hose Bundle Part Numbers
4 309572ZAT
Standard 2 Component Hose
Airless 2 Component Hose
Hose
Assembly
Length
ft (m)
ID
in. (mm)
FTS
Cable
Standard
Braided
Scuff
Guard
Xtreme-W
rap Scuff
Guard
Hose Fittings
“A
Red Hose
“B”
Blue Hose ETL Approval
“A”
inlet (f)/
outlet (m)
“B”
inlet (f)/
outlet (m)
2000 psi (13.8 MPa, 138 bar)
246045 50 (15.2) 1/4 (6) ✓ -5 JIC -6 JIC 246059 246060
246046 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246061 246062
246047 50 (15.2) 1/2 (13) ✓ ✓ -8 JIC -10 JIC 246063 246064
246074 50 (15.2) 1/4 (6) -5 JIC -6 JIC 246059 246060
246075 50 (15.2) 3/8 (10) -5 JIC -6 JIC 246061 246062
246076 50 (15.2) 1/2 (13) -8 JIC -10 JIC 246063 246064
246678 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246061 246062
24Y678 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246061 246062
256549 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246061 246062
24Y549 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246061 246062
249587 25 (7.6) 1/4 (6) -5 JIC -6 JIC 246065 246066
261328 25 (7.6) 3/8 (10) -5 JIC -6 JIC 246094 246095
246048 25 (7.6) 1/4 (6) ✓ -5 JIC -6 JIC 246065 246066
246049 25 (7.6) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246094 246095
3500 psi (24.1 MPa, 241 bar)
246052 50 (15.2) 1/4 (6) ✓ -5 JIC -6 JIC 246067 246068
246053 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246069 246070
246054 50 (15.2) 1/2 (13) ✓ -8 JIC -10 JIC 246071 246072
249588 50 (15.2) 3/8 (10) -5 JIC -6 JIC 246069 246070
246679 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246069 246070
24Y679 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246069 246070
256548 50 (15.2) 1/2 (13) ✓ ✓ -8 JIC -10 JIC 246071 246072
261335 50 (15.2) 1/2 (13) -8 JIC -10 JIC 246071 246072
26C193 25 (7.6) 3/8 (10) -5 JIC -6 JIC 246094 246095
5000 psi (34.5 MPa, 345 bar)
261332 25 (7.6) 3/8 (10) -5 JIC -6 JIC
262203 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 15E751 15E752
RECOGNIZED
COMPONENT
5024314
Certified to CSA STD C22.2
No. 88
Conforms to UL STD 499
RECOGNIZED
COMPONENT
5024314
Certified to CSA STD C22.2
No. 88
Conforms to UL STD 499
Hose
Assembly
Length
ft (m)
ID in. (mm)
FTS
Cable
Standard
Braided
Scuff
Guard
Hose Fittings
“A”
Red Hose
“B”
Blue Hose“A” “B”
“A” inlet (f)/
outlet (m)
“B” inlet (f)/
outlet (m)
5000 psi (34.5 MPa, 345 bar)
248907 50 (15.2) 1/4 (6) 3/8 (10) ✓ -5 JIC -6 JIC 15E750 15E752
248908 50 (15.2) 3/8 (10) 3/8 (10) ✓ -5 JIC -6 JIC 15E751 15E752
262727 50 (15.2) 1/2 (13) 1/4 (6) ✓ -8 JIC -6 JIC 262719 262718
262728 50 (15.2) 1/2 (13) 3/8 (10) ✓ -8 JIC -6 JIC 262719 15E752
262730 50 (15.2) 1/2 (13) 1/2 (13) ✓ -8 JIC -10 JIC 262719 262720
