Power-Lock Hose Bundle Part Numbers
309572ZAT 5
RTD 2-Component Hose (for use with GCA Controlled Reactors)
Custom Application 2 Component Hose
‡ Two FTS cables and two sets of standard wires.
Hose
Assembly
Length
ft (m)
ID
in. (mm)
RTD
Cable
Standard
Braided
Scuff
Guard
Xtreme-
Wrap
Scuff
Guard
CAN
Cable
Hose Fittings
“A”
Red
Hose
“B”
Blue
Hose ETL Approval
“A”
inlet (f)/
outlet (m)
“B”
inlet (f)/
outlet (m)
2000 psi (13.8 MPa, 138 bar)
24K240 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246061 246062
24Y240 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246061 246062
24K394 50 (15.2) 3/8 (10) ✓ ✓ ✓ -5 JIC -6 JIC 246061 246062
24T839 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246061 246062
24Y394 50 (15.2) 3/8 (10) ✓ ✓ ✓ -5 JIC -6 JIC 246061 246062
24N000 50 (15.2) 1/2 (13) ✓ ✓ -8 JIC -10 JIC 246063 246064
24N001 50 (15.2) 1/2 (13) ✓ ✓ ✓ -8 JIC -10 JIC 246063 246064
3500 psi (24.1 MPa, 241 bar)
24K241 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246069 246070
24Y241 50 (15.2) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246069 246070
24K395 50 (15.2) 3/8 (10) ✓ ✓ ✓ -5 JIC -6 JIC 246069 246070
24Y395 50 (15.2) 3/8 (10) ✓ ✓ ✓ -5 JIC -6 JIC 246069 246070
24U743 50 (15.2) 3/8 (10) ✓ -5 JIC -6 JIC 246069 246070
24N002 50 (15.2) 1/2 (13) ✓ ✓ -8 JIC -10 JIC 246071 246072
24N003 50 (15.2) 1/2 (13) ✓ ✓ ✓ -8 JIC -10 JIC 246071 246072
Hose
Assembly
Length
ft (m)
ID in. (mm)
FTS
Cable
RTD
Cable
Standard
Braided
Scuff
Guard
Hose Fittings
“A”
Red
Hose
“B”
Blue
Hose ETL Approval“A” “B”
“A”
inlet (f)/
outlet (m)
“B”
inlet (f)/
outlet (m)
2000 psi (13.8 MPa, 138 bar)
255089 50 (15.2) 1/4 (6) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246059 246062
25A482 50 (15.2) 1/4 (6) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246059 246062
3500 psi (24.1 MPa, 241 bar)
247164 50 (15.2) 1/4 (6) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246067 246070
261336 50 (15.2) 3/8 (10) 1/2 (13) ✓ -5 JIC -6 JIC 246069 246072
261337 50 (15.2) 1/4 (6) 3/8 (10) ‡ -5 JIC -6 JIC 246067 246070
24N524 50 (15.2) 1/4 (6) 1/2 (13) ✓ ✓ -5 JIC -10 JIC 246067 246072
25A481 50 (15.2) 1/4 (6) 3/8 (10) ✓ ✓ -5 JIC -6 JIC 246067 246070
25A484 50 (15.2) 3/8 (10) 1/2 (13) ✓ -5 JIC -6 JIC 246069 246072
25A485 50 (15.2) 1/4 (6) 3/8 (10) ‡ -5 JIC -6 JIC 246067 246070
25A483 50 (15.2) 1/4 (6) 1/2 (13) ✓ ✓ -5 JIC -6 JIC 246067 246072
RECOGNIZED
COMPONENT
5024314
Certified to CSA STD C22.2
No. 88
Conforms to UL STD 499
RECOGNIZED
COMPONENT
5024314
Certified to CSA STD C22.2
No. 88
Conforms to UL STD 499
RECOGNIZED
COMPONENT
5024314
Certified to CSA STD C22.2
No. 88
Conforms to UL STD 499
