LED indicators.

When switched on, the LCD display shows the following:

COMPRAG SCREW

AIR COMPRESSOR

The main parameters of the compressor are displayed after 5 seconds:

21°C 0.00HZ

Oil/air mixture temperature at the

compressor outlet

Current motor frequency

0.0BAR 0RPM Pressure at the compressor outlet Current motor speed

STOP Operating status of the compressor

0.00V O.0kW Current mains voltage

Current power consumption of the

compressor

Main menu: Click in order to bring up the options menu:

RUN PARAMETERS Includes current values (available for viewing)

USAGE PARAM

Includes operating settings of the main parameters (available for viewing,

changes password-protected)

FACTORY PARAM For servicing mode (view with password). Modication only possible by manufacturer

Description of the parameters. Run parameters:

Select the run parameters using the up and down buttons and enter . Current values

are displayed.

FAN, VSD PARAM

TOTAL RUN TIME

THIS RUN TIME

MAINTEN. PARAM

ERRORS HISTORY

MFD, SERIAL NO

THIS ERROR

DESCRIPTION

Run parameters. Select the run parameters using the up and down buttons and enter .

FAN, VSD PARAM

FREQUENCY 50.0 Hz

VOLTAGE 400V

CURRENT:

POWER:

At the output of the frequency inverter.

FAN CURRENT (A)

А: 0.0

В: 0.0

С : 0.0

Current consumption of all 3 phases of the fan.
