Comprag AV5510 [20/96] Version 1

Version 1.4

Select the usage parameters using the up and down buttons and enter .

SET P, T, FREQ

SET TIME

OPERATION MODE

SEQ PARAM SET

RST MAINT TIME

MAX RUN TIME

USER PASS:

LANG.

SET P, T, FREQ — set pressure and temperature

(Below are the example set values for the compressor with the max. 8-bar operating pressure).

P LOAD 05.2 BAR If the compressor is ready, it switches at this pressure to loaded running.

P ULD 08.00 BAR At this pressure the compressor switches to idle running.

FREQ P 007.0 BAR Set pressure of the frequency inverter.

T FAN 0095°C Switch-on temperature of the fan.

T FAN STOP 0060°C Switch-off temperature of the fan.

RAT. POWER 75.0kW Rated power of the electric motor.

RATED SPEED 2940RPM Rated speed of the electric motor.

SET TIME

FAN DELAY: 0002S Delay in overloading fan.

LOAD DELAY: 0002S Delay in load run (suction valve open).

IDLE DELAY: 0300S Idle run time. Suction valve closed, and main motor running.

STOP DELAY: 0005S Switch-off delay with off button. Suction valve closed, and main motor running.

START DELAY: 0040S Delay in restart. Drop in system pressure.

SPEED INCR: 0625 PID setting for the maximum speed increase.

SPEED DECR: 0625 PID setting for maximum speed reduction.

Operational mode

RUN REMOTE/LOCAL Switch on by remote control or locally via the control.

LOAD AUTO/MANUAL Loaded running/idle running automatically or manually.

COM: PC/BAN/GRP Communication mode: PC / MODBUS / group.

COM ADDRESS: 001 Communication port, network address.
