Asus TUF GAMING X570-PRO (WI-FI) [17/68] Chapter 1

TUF GAMING X570-PRO (WI-FI)

1-5

Chapter 1

2. DIMM slots

The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4

(Double Data Rate 4) memory modules.

A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO

NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.

DIMM_B1

DIMM_B2*

DIMM_A1

DIMM_A2*

Recommended memory configurations

DIMM_A1

DIMM_A2*DIMM_A2*

DIMM_B2*

DIMM_A2*

DIMM_B1

DIMM_B2*
