1-8
Chapter 1: Product Introduction
Chapter 1
3
rd
Gen AMD Ryzen™ Processors
VGA Configuration
PCIe operating mode
PCIe 4.0 x16_1 PCIe 4.0 x16_2
Single VGA/PCIe card x16 N/A
Dual VGA/PCIe card x16 x4
2
nd
Gen AMD Ryzen™ and 3
rd
Gen AMD Ryzen™ with Radeon™ Graphics
Processors
VGA Configuration
PCIe operating mode
PCIe 3.0 x16_1 PCIe 4.0 x16_2
Single VGA/PCIe card x16 N/A
Dual VGA/PCIe card x16 x4
2
nd
and 1
st
Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
VGA Configuration
PCIe operating mode
PCIe 3.0/2.0x16_1 PCIe 4.0 x16_2
Single VGA/PCIe card x8 N/A
Dual VGA/PCIe card x8 x4
• We recommend that you provide sufficient power when running CrossFireX™ mode.
• Ensure to connect the 8-pin and 4-pin power plugs when running CrossFireX™
mode.
• Connect chassis fans to the motherboard chassis fan headers when using multiple
graphics cards for better thermal environment.
