vii
TUF GAMING X570-PRO (WI-FI) specifications summary
Ethernet
1 x Intel
®
I225-V 2.5Gb Ethernet
TUF LANGuard
Wireless &
Bluetooth
Intel
®
Wi-Fi 6 AX200
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) supports 1024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max. data rate
Supports 2.4/5GHz Dual-Band
Supports channel bandwidth: HT20/HT40/HT80/HT160
Supports PCIe interface
Bluetooth v5.1*
* Bluetooth 5.1 function will be ready in Window 10 build 19041 or later.
USB
Rear USB (Total 7 ports)
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C
®
)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
Front USB (Total 7 ports)
1 x USB 3.2 Gen 2 front panel connector (supports USB Type-C
®
)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio
Realtek ALC S1200A 7.1 Surround Sound High Definition Audio
CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192kHz playback
Audio Features:
- Audio Shielding
- Rear optical S/PDIF out port
- Premium Japanese audio capacitors
- Dedicated audio PCB layers
- Audio cover
Back Panel I/O Ports
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C
®
)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
1 x DisplayPort
1 x HDMI
TM
port
1 x ASUS Wi-Fi Module
1 x Intel
®
I225-V 2.5Gb Ethernet port
5 x Audio jacks
1 x BIOS FlashBack™ button
1 x Optical S/PDIF out port
1 x PS/2 Keyboard/Mouse combo port
(continued on the next page)
