Asus TUF GAMING X570-PRO (WI-FI) [36/68] Cooling system installation

2-2

Chapter 2: Basic Installation

Chapter 2

2.1.2 Cooling system installation

Apply Thermal Interface Material to the

CPU cooling system and CPU before you

install the cooling system, if necessary.

Type 1

1 2

3 4
