Asus TUF GAMING X570-PRO (WI-FI) [48/68] Wi fi antenna installation

2-14

Chapter 2: Basic Installation

Chapter 2

2.1.10 Wi-Fi antenna installation

Installing the ASUS 2x2 dual band W-Fi antenna

Connect the bundled ASUS 2x2 dual band Wi-Fi antenna connector to the Wi-Fi ports at the

back of the chassis.

• Ensure that the ASUS 2x2 dual band Wi-Fi antenna is securely installed to the Wi-Fi

ports.

• Ensure that the antenna is at least 20 cm away from all persons.

The illustration above is for reference only. The I/O port layout may vary with models, but

the Wi-Fi antenna installation procedure is the same for all models.
