Asus TUF GAMING X570-PRO (WI-FI) [40/68] M installation

2-6

Chapter 2: Basic Installation

Chapter 2

2.1.4 M.2 installation

Supported M.2 type varies per motherboard.

OPTIONAL

• The M.2 rubber pad is

optional for when installing

a single sided M.2 storage

device. Ensure to install the

bundled M.2 rubber pad

before installing your single

sided M.2 storage device.

• DO NOT install the bundled

M.2 rubber pads when

installing a double-sided

M.2 storage device. The

rubber pad installed by

default is compatible with

double sided M.2 storage

devices.
