CS1922M / CS1924M User Manual
4
Requirements
Console
A DisplayPort or HDMI monitor capable of the highest possible resolution
A USB mouse
A USB keyboard
Microphone and speakers
Computers
The following equipment must be available on each computer:
DisplayPort port
USB Type-A port
Audio ports
Cables
To guarantee video quality we recommend using only ATEN DisplayPort
KVM cables which are certified by the VESA Compliance Program. Two
(CS1922M) or four (CS1924M) cables are provided with this package.
Note: 1. The video quality displayed is affected by the quality and length of the
cables you use. We recommend the total length from the source to the
monitor not exceed 3 meters. If you need additional cable sets, please
contact your dealer to purchase ATEN approved cables.
2. If you use DisplayPort cables that are DP 1.1 compliant, make sure
the DisplayPort EQ setting on the monitor is set to auto or DP 1.1.
