Chapter 1. Introduction

No. Component Description

1 port selection

pushbuttons

For manual port selection (see Manual Switching, page 13):



Press a port selection pushbutton for less than two seconds to

bring the KVM, USB hub, and audio focus to the computer

attached to its corresponding port.



Press a port selection pushbutton twice to bring the audio focus to

the computer attached to its corresponding port.



Press a port selection pushbutton for longer than two seconds to

bring only the KVM focus to the computer attached to its corre-

sponding port.



Press port selection pushbutton 1 and 2 simultaneously for 2 sec-

onds to start Auto Scan Mode (see Auto Scanning, page 26).

2 port LEDs The port LEDs are built into the port selection pushbuttons. The upper

are KVM Port LEDs; the lower are USB LEDs:

KVM



Lights DIM ORANGE to indicate that the computer attached to the

corresponding port is connected (online).



Changes to BRIGHT ORANGE to indicate that the computer

attached to its corresponding port is the one that has the KVM

focus (Selected).



Flashes to indicate that the computer attached to its corresponding

port is being accessed under Auto Scan mode.

USB



Lights GREEN to indicate that the computer attached to its corre-

sponding port is the one that has access to the USB peripherals.

3 audio ports The cables from your main speakers and main microphone plug in

here. The speakers and microphone plugged in here have priority

over those on the rear panel.

4 USB 3.0 port USB peripherals (printers, scanners, drives etc.) plug into this port.

This USB 3.1 Gen 1 port features 5 Gbps data transfer rates for

compatible USB peripherals.
