![Aten CS1922M [42/64] Keyboard emulation](/views2/1977313/page42/bg2a.png)
CS1922M / CS1924M User Manual
32
Keyboard Emulation
The console keyboard port emulation/bypass feature supports most gaming/
multimedia keyboards. The default setting is enabled. To disable, do the
following:
1. Invoke HSM (see page 27).
2. Press [N].
This procedure is a toggle. Repeat to revert to the original setting.
Note: When keyboard emulation is disabled, the [M], [Q], [W], [F2], [F4],
[F5], [F6], and [F10] hotkey operations are disabled.
Power on Detection
With Power on Detection, if the focus computer is powered off, the switch will
automatically switch to the next powered-on computer. Power on Detection
can be enabled or disabled. The default setting is enabled. To disable Power on
Detection, do the following:
1. Invoke HSM (see page 27
).
2. Press and release [E].
This procedure is a toggle. Repeat to revert to the original setting.
Monitor Re-detection
If the monitor's display is blank, use this hotkey to re-detect the monitor’s
EDID. Monitor re-detection can be enabled or disabled. The default setting is
disabled. To enable monitor re-detection, do the following:
1. Invoke HSM (see page 27
).
2. Press [Q] [n] [Enter].
n is a one-digit number that represents the port number: n=1-2
(CS1922M); or n=1-4 (CS1924M).
This procedure is a toggle. Repeat to revert to the original setting.
