Chapter 4. Hotkey Operation

HSM Summary Table

After invoking HSM (see page 27), key in one of the following keys to perform

the corresponding function:

Key Function

[B] Toggles the beeper On and Off.

[E] Enable/Disable the Power on Detection feature.

[F] Enable/Disable Multi-Stream Transport (MST) mode.

[H] Toggles between the default and alternate HSM

invocation keys.

[M] Toggles between mouse emulation enable and disable.

[N] Enable/Disable keyboard emulation.

[Q] [n] [Enter] Enable/Disable monitor re-detection on port [n].

[R] [Enter] Resets the hotkey settings to their default statuses.

[S] Toggles between the default and alternative pushbutton

operation settings.

[T] Toggles between the default ([Scroll Lock] [Scroll Lock])

and alternate ([Ctrl] [Ctrl]) Port Switching keys.

[U][P][G][R][A][D][E] [Enter] Invokes Firmware Upgrade Mode.

[W] Enable/Disable mouse port switching

[X] [Enter] Enable/Disable the Port Switching keys.

[F1] Allows the keyboard and mouse to work under special

operating systems as a standard (104 key) keyboard/

mouse.

[F2] Enables Mac keyboard emulation.

[F4] Print the switch’s current settings via a text editor or

word processor.

[F5] Performs a reset on all USB devices.

[F6] [nn] [Enter] Sets the keyboard language. nn represents one of the

following keyboard language codes: US English: 33;

French: 08; Japanese: 15; German: 09.

[F10] Auto detects the keyboard operating platform.
